Specifications:

• Thiele/Small Parameters
• 49L7X122 T/S Parameters
• Size (in, cm)
• 12, 30
• Rated Impedance (Ohms)
• 2 DVC
• Rec Amp Power rms
• 1000-2000
• Frequency Response
• 20-100
• Magnet Diameter (in, cm)
• 8-15/16, 22.7
• Total Magnet Weight (oz, kg)
• 406, 11.5
• Voice Coil Diameter (in, mm)
• 3, 75
• Voice Coil Winding Width (in, mm)
• 2.5, 62.5
• Product Dimension Sheet
• 49L7X12 Dimensions
• Top Plate Thickness (in, mm)
• 0.5, 13
• Xmax (in, mm)
• 1.25, 31.25
• Mounting Cutout (in, cm)
• 11-1/16, 28.1
• Mounting Depth (in, cm)
• 10-1/8, 25.7
• Recommended Vented Box Volume (Cu. Ft., L)
• 3, 84.9
• Port Opening (in x in, cm x cm)
• 3.5 x 13, 9 x 33
• Port Length (in, cm)
• 36.5, 93
• Vented Enclosure Tuning Frequency (Hz)
• 31
